INDY Carver

Indy was designed from the beginning to be a high gantry carving machine, Rigidity is core to its design. Special attention to high speed and acceleration on the z axis makes Indy faster than all most all its competitors. Indy is our standard size chassis professional routing and carving table, and with 12" work height and rotary axis option there is nothing small in it capabilities. It is more compact but just as productive as its larger brother. Indy uses much of the Pro design in a smaller package that maximizes output from a small footprint Available in 4ft by 8ft and 4ft by 10ft bed sizes.

FEATURES

  • Very rigid construction without extra weight makes the Indy tough as well as fast

  • Our unique cross-bolted assembly allows perfect squaring during assembly, unlike welding

  • Lift out tabletop sections for custom setups, drop-in jigs or 4th axis rotational work

  • Helical gearboxes eliminate backlash in the gear train

  • Teknic servo motors: powerful, accurate, resistant to electrical noise, the highest quality in their class

  • Highest quality SKF linear bearings throughout for best accuracy, reliability and long life

  • Standard 4kw spindle or optional 4.5 HP custom-built spindle with a TG-75 collet. Specially designed for supporting long cutting tools with unparalleled accuracy to reduce vibration and run-out.

  • 220 Volt single phase configuration allows installation in more locations – no need for 3 phase power

  • Helical 10:1 gearboxes, high quality and low backlash with high acceleration rates.

  • Helical rack and pinion gear drive on all axes

An example of fine 3d carving machined by an Indy Carver

Courtesy Moonscapes

DIMENSIONS

Length: 120” (304.8 cm) (8ft bed) or optional 144” (365.8 cm) (10ft bed)



Width:  78” (198 cm)



Height: (Max) 76” (193 cm)



Electrical requirements: 220-240 Volt 40 Amp single phase 50 or 60 Hz

WORK AREA

Length: 97” (246.0cm) or optional 121” (307 cm)



Width:  52” (157.5 cm)


Height: clearance under gantry 12” (30.5 cm) (Max travel 12” (30.5 cm))

PACKAGE INCLUDES

Machine with spindle, wrenches & collets



PC with Windows 10 and WinCNC installed and ready to run



21” 1280p monitor



All cables

​

13-month warranty on all parts and workmanship.



Non-expiring technical support, you call - we help.
